Example API calls

Here is an illustration of API calls that can give you a kickstart.

You can grab this as a Postman collection

Watermark in the top-left corner of the video


curl --location --request POST 'http://localhost:5080/LiveApp/rest/stamp/instructions'
 --header 'Content-Type: application/json' --data-raw '
{
  "id": "watermark-1",
  "start":"now", "end":"2100.01.01 00:00:00.000",
  "image": "/tmp/live-logo.png",
  "position":{"x":10,"y": 10, "z":2, "anchor":"top-left"}
}
'

Text in the middle of the screen with fade-in

Displayed with 5 second fade-in for 120 seconds and then removed.

curl --location --request POST 'http://localhost:5080/LiveApp/rest/stamp/instructions'
 --header 'Content-Type: application/json' --data-raw '
{
    "id": "myText1",
    "start": "now",
    "duration": 120,
    "text": "Hello Stamp",
    "position": {"x": 0.5, "y": 0.5, "anchor": "center-center"},
    "style": {"font":"Verdana", "size":40, "style": "bold", "color": "yellow"},
    "transitionIn": {"type": "fade", "duration": 5},
    "shadow": {"radius": 3 }
}
'

Image downloaded from external URL

Delayed with 2 seconds after sending in, faded in, kept and then faded out.

{
    "id": "img-1234",
    "start": "now+2",
    "duration": 30,
    "image": "https://streamtoolbox.com/images/streamtoolbox-white-transparent-logo.png",
    "position": {"x": 100, "y": 100, "anchor": "top-left"},
    "transitionIn": {"type": "fade", "duration": 5},
    "transitionOut": {"type": "fade", "duration": 5}
}

Ticker at the bottom of the screen

{
  "start": "now+1", "end": "2100.12.31 12:00:00",
  "text": "This is really breaking news here",
  "position": {"x": 0.5, "y": 0.9},
  "style": {"font":"Verdana", "size":62, "style": "bold", "color": "yellow"},
  "transitionIn": {"type":"ticker", "speed": 4}
}

Big clock in the top left corner

{
  "clock":"HH:mm:ss",
  "start":"2000.01.01 00:00:00.000","end":"2100.01.01 00:00:00.000",
  "style": {"font":"sansserif", "color":"#ffffff","style":"bold","size":40},
  "position":{"x":100.0,"y":100.0,"z":2,"anchor":"top-left"}
}

HTML Overlay using overlays.uno

You can register on http://overlays.uno for a free account and grab your own overlay. Swap the url in the below example to your own custom output url that you can control. You can use the cropWidth, cropHeight options to trim the HTML overlay to a smaller rectangle and get better performance by not processing the transparent areas unnecessarily.

{
  "id": "overlay1",
  "start":"2000.01.01 00:00:00.000","end":"2100.01.01 00:00:00.000",
  "html": {
      "url": "https://app.overlays.uno/output/2VgYWfN6uPom34Mf9LhU2t?aspect=16x9"
  },
  "position":{"x":0,"y":0,"z":2,"anchor":"top-left"}
}
